From My Home Good Stove
From My Home Good Stove
From

"My Home Good Stove" is a low cost efficient good stove of Magh series. http://goodstove.com . Also see [My Home Stove 2](http://myhomestove2.blogspot.com/) http://myhomestove2.blogspot.com/It is also safe, low heat conduction to the stove body mass, low weight, saves 30% to 50% fuel as compared to traditional stoves, convenient for using all types of biomass fuels. The temperature of the flame is around 400 to 500 degree centigrade and reaches maximum of 700 degree centigrade. Convenient for cooking all types of food. http://myhomestove.blogspot.com/ This stove lasts longer due to use of steel mesh inside, which is low cost and easily replaceable. Other wise majority of metal stoves last around one year only. This stove is named as My home because it appears like home.

MAGH 3G GOOD STOVE

Most adopted stove by poor, tribals and farmers in parts of Andhra Pradesh, India, Already facilitated 1500 stoves and the demand is growing every day.
For more details see links:
http://www.bioenergylists.org/content/magh-3g-stove-all | http://e-magh3g.blogspot.com/


[MAGH OPEN STOVE](http://e-maghopenstove.blogspot.com/) is an institutional fixed woodgas stove. This stove is useful for cooking needs of up to 100. With primary and secondary air controls it is easy to operate and highly efficient. For making this stove, "Magh CM" stoves are used inside. This stove is installed at "Open House", Hyderabad, a place for destitute youth for cooking their own food, shelter, studies, etc. Implemented under the "Good Stoves and Biochar Communities" Project, Implemented by GEO with support of GoodPlanet.org France. Stove design by Dr. N. Sai Bhaskar Reddy. For more details visit http://e-maghopenstove.blogspot.com/

[MAGH 3G]( http://e-magh3g.blogspot.com/ ) is an adaptation stove. All types of biomass, briquettes and charcoal can be used for cooking. This is an all in one stove.

It was found that many families have at least two or three types of stoves in rural areas for using types of biomass as fuel. Now with just one stove they have the freedom to use all types of Biomass as fuel.

There is an option to control primary air, to control air from the fuel feed side opening, and secondary air (while using TLUD adopter). Weighs less than 2 kgs, 9 inches in height and 7 inches diameter. Most convenient for regular use, travel, relief, refugees, etc. Reusing metal sheet, these stoves are completely hand made. The cost of each stove piece is $5 (USD).

This stove is being facilitated under the "Good Stoves and Biochar Communities" Project, implemented by GEO with the support of GoodPlanet.org This is one of the 40 stoves designed by Dr. N. Sai Bhaskar Reddy, GEO http://www.e-geo.org http://www.goodstove.com/ . For more details visit http://e-magh3g.blogspot.com/

Paal Wendelobo, January 2010

Attached you will find a prospect of the new TLUD called MUS (multi use stove).

MUS The multi-use stove.

I’ve been following a couple of different groups and discussions to learn about biochar for about 6 months. Id like to share what I’ve been learning and ask a couple of questions.

My purpose is to use biochar as a component in biological soil synthesis and buffer for use in a vaquaculture growing system.

I have been making small TLUD stoves, observing modeling tweaking making another.

Btu Calculator

desc=Excel sheet by Ken Smith. Water boil and Btu

A great Excel sheet pertaining to different species of wood.

Snip:

Center Fire Stove 01 Cooking Test
Lanny Henson, June 12, 2006

In the last cooking test, the Center Fire Stove 01 needed only 750
grams/1.65 lb of pine chips to cook 8 pounds/3.63 kilograms dry weight of pintos. That is 14 liters of volume with water or 104 servings-35 gr/ 1/2 cup cooked volume (1/4 cup dry weight) servings.

Lanny Henson June 4, 2006

This modular stove is built from used metal containers.

It has a center fire burner module, a sunken 8-liter pot module, and an insulated/ chip drying top cap.
The burner and is made from an institutional food can. It takes all the ware and stress from the fire protecting the rest of the stove body.They are easy to build and can act as fuel cartridges to store fuel for quick and easy use.
The burner module, under development, adds secondary combustion air to the top of the burner.

Lanny Henson's Center Fire Stove 01Lanny Henson's Center Fire Stove 01
