Summary of Stove Camp 2007

Summary of Stove Camp 2007
Dean Still, Nordica MacCarty, Aprovecho Research Center
Tom Miles and Paul AndersonTom Miles and Paul Anderson Amaze Folks at Stoves Camp

July 16th to 20th, 25 participants joined the Aprovecho staff in the lab for the 7th annual summer stove camp. Organizations represented included the International Lifeline Fund for Darfur, CEIHD, UCB, University of Illinois Bond Research Group, Trees Water People, SEA Limited, AidAfrica, GIRA, Colorado State University, Create, and the University of Oregon. People came from India, Darfur, Mexico, Cameroon, and the US.

A good time was had by all as we camped, cooked lunch on wood burning stoves, shared information, and built and tested stoves. This year was a bit different because we did classes every day for most of the participants. I hope that folks went away feeling better informed.

I learned a lot from Dale Andreatta about heat transfer and thought that the group succeeded in writing up a more effective Controlled Cooking Test. Chris Roden and Nordica shared up to the minute Global Warming data. It was interesting to help folks design stoves for their applications. It is always a pleasure to see Paul Anderson’s enthusiasm for T-LUD’s! I think that his continual feed T-LUD shows a lot of promise.

Key discussions included:
- Revising the CCT to allow for simple language and recommendations
- Global warming potentials of six common stoves, climate forcing, and black/white particles
- PEMS demonstration and training
- Combustion Class
- Emissions Monitoring Class
- Design principles, heat transfer, and combustion efficiency
- Rocket stove building
- Justa stove building, and outdoor kitchen demonstrations
- Intro to Global Warming research
- Global Warming data presentation
- TLUD Gasifiers
- Vermiculate & Clay brick making
- CCT re-write (Continued)
- Advanced Heat Transfer
- Selling Stoves Business Plan Development
- WBT Testing w/Emissions
- Institutional Stoves
- Stoves w/Chimneys

This year the continual flow of classes replaced a lot of the stove development and testing. In fact, we decided not to award the 2nd Annual Cat Pee Award since there were few contestants. Three stoves were tested under the PEMS and the results are seen in the table below:

Continuous TLUD THING Bucket Rocket with Big Hood
Fuel (g/L) 231 113 117
CO (g/L) 1.2 4.3 5.5
PM (g/L) 63 62 165

Tom Miles happened to be in the lab when the THING was being tested. The THING is an adjustable skirt surrounding a pot (11mm gap) that only allows air to enter into the combustion zone through the one fuel entrance. The pot sits on top of a separate pot support inside the skirt. The sticks burn relatively slowly at the tips. The small gap between the skirt and the pot diminishes primary air compared to the Rocket stove. As can be seen from these single tests the THING made a relatively small amount of PM but was higher than the TLUD on CO.

We are continuing to experiment with what we now view as a continuum from gasifier to Rocket with the THING somewhere in the middle.

Stove Camp Pictures, click on each image for more detail.

Dean and Damon Cooking LunchDean and Damon Cooking LunchKen stirring the beansKen stirring the beansDamon discussing stove constructionDamon discussing stove constructionMiguel lecturing studentsMiguel lecturing students

Ken Goyer discussion Uganda, Darfur and Stove projectsKen Goyer discussion Uganda, Darfur and Stove projects

Dean lighting the modified VITA StoveDean lighting the modified VITA StoveJohn demonstrating insulative monolithic stove bodiesJohn demonstrating insulative monolithic stove bodiesPreparing the vermiculite mixPreparing the vermiculite mixSetting up a simple moldSetting up a simple moldSome finished stove bodiesSome finished stove bodiesTesting the finished stove bodiesTesting the finished stove bodiesErnestine and Paul cook on the TLUDErnestine and Paul cook on the TLUDReplacing the TLUD burner with a new oneReplacing the TLUD burner with a new oneThe TLUD burnerThe TLUD burnerAdjusting air on the TLUD burnerAdjusting air on the TLUD burner
